F@st 3284 DC High Performance Multimedia Home Gateway

Sagemcom · F@st 3284 DC DNA
Condition

Feature Highlights

DOCSIS 3.0 / EuroDOCSIS 3.0 WAN Access
8x4 Channel Bonding
Dual-Band WiFi 4 (N)
300 Mbps on 5Ghz 2x2 MIMO
300 Mbps on 2.4Ghz 2x2 MIMO
4 x Gigabit Ethernet LAN
1-Year Warranty
30-Day Returns
Essential Support

Please feel free reach out to us with any questions.

Email +36 70 625 7203
Description
Technical Specifications

Sagemcom F@st 3284 is a residential gateway mainly targeted to provide broadband Internet access through a DOCSIS 3.0 cable network. With the Sagemcom F@st 3284 and the associated set-top-boxes, the user gets access to 3-play services with a high level of quality:
• Up to 400 Mbps Downlink and 140 Mbps Uplink throughput
• High quality Voice over IP communication are based on the MGCP protocol but also on SIP
• High power Wi-Fi

Interfaces • Network:
– DOCSIS 3.0 8x4

• User:
– 4 Eth 10/100/1000 Base-T
– 2 USB 2.0 host for Accessories
– 802.11b/g/n, Wi-Fi access point in 2.4GHz
– High Power or 5GHz band (option)
– Wi-Fi ON/OFF button
– 2 FXS
Wireless Security • WPA/WPA2/WEP with 64 or 128 bits key
• MAC Address Access List
• WPS
• Wi-Fi Alliance certified
Network • DOCSIS 3.0:
– Channel bonding 8x4
– Backward compatible with DOCSIS 1.0/2.0 and 2.0b
– Compatible with EuroDOCSIS and US DOCSIS frequencies
PPP Functions • PAP/CHAP
• Multi PPPoE sessions
• PPPoE client termination
• PPPoE session pass-through
IP Functions • General:
– NAT/PAT
– DHCP client and server
– DNS relay

• IPv6:
– Dual stack
– DSLite

• Routing:
– Static/dynamic routing

• IGMP Proxy/snooping

• Firewall:
– Address, port and protocol filtering
– State full Packets Inspection

• Quality of service: DiffServ
• L2TP
Voice over IP (VoIP) • Protocol NCS, MGCP or SIP
• Voice coding:
– G.711 (64 kbps)
– G.729 (8 kbps)
Management • Firmware upgrade by TFTP
• Auto provisioning and remote configuration
• SNMP
• TR-069
Electricity Safety • Compliant with EN 60 950, EN 41003
Environment • Operating temperature: 5°C to 45°C
• EMC: 89/336EEC, EN 55022 Class B, EN 55024
• IEEE Wi-Fi b/g/n/11ac compliant
• CE
