Velop WiFi 6 Whole Home Mesh Tri‑Band MX4200 Node
Feature Highlights
Gigabit Ethernet WAN AccessTri-Band WiFi 6 (AX)
2.400 Mbps on 5Ghz 4x4 MU-MIMO
1.200 Mbps on 5Ghz-2 2x2 MU-MIMO
574 Mbps on 2.4Ghz 2x2 MIMO
3 x Gigabit Ethernet LAN
Couldn't load pickup availability
Certified Pre-Owned
Unused Pre-Owned
Please feel free reach out to us with any questions.
The Linksys Velop® WiFi 6 AX4200 Whole Home Mesh Tri‑Band System delivers next-level streaming and gaming to more than 40 devices on your network. With easy set up, advanced security and parental controls, Velop® WiFi 6 AX4200 is an essential upgrade to any home.
Sending and receiving multiple streams of data simultaneously, WiFi 6 (AX) has 3,5x the capacity of WiFi 5 (AC) technology. The Velop® WiFi 6 AX4200 Whole Home Mesh Tri‑Band System can handle as many as 40 devices, so laptops, televisions, smart-home systems and more can all operate simultaneously with ease. BSS Colouring technology minimises congestion by eliminating interference from nearby wireless networks delivering a strong, clear wireless signal throughout your home.
As with any Velop mesh WiFi node, increasing your coverage is as simple as adding any other Velop mesh WiFi node.
| Specifications | |
|---|---|
| WiFi Specifications |
WiFi AX4200* with 8-stream WiFi, 4×4 MU-MIMO and 1024-QAM Radio 1 – 2.4 GHz Band 802.11ax – 574 Mbps* Radio 2 – 5 GHz Band 802.11ax – 1201 Mbps* Radio 3 – 5 GHz Band 802.11ax – 2402 Mbps* Simultaneous Tri-Band IEEE 802.11 b/g/n – 2.4 GHz – 1024 QAM support. IEEE 802.11 a/n/ac/ax – 5 GHz – 1024 QAM support. Tri-Band Dynamic Backhaul OFDMA Technology Downlink and uplink MU-MIMO supported Advanced Beamforming+ technology Seamless roaming technology. |
| Processor and Memory |
AX optimised 1.4 GHz Quad-Core 512 MB Flash and 512 MB RAM |
| Bluetooth | 4.0/LE for secure and easy App-based Setup. |
| Security |
WPA2 personal encryption, WPA2 / WPA3 Mixed Mode. |
| Wired Connectivity |
4× Gigabit Ethernet ports (1× WAN, 3× LAN) 1× USB 3.0 port for SMB file sharing, FTP and UPNP/DLNA media streaming. |
| Radio Operating Frequencies |
2.4 GHz ………………… 2412–2472 MHz 5 GHz …………………… 5180–5240 MHz, ……………………………… 5260–5320 MHz, ……………………………… 5500–5700 MHz, ……………………………… 5700–5730 MHz Bluetooth ……………… 2400–2483 MHz |
| Antenna Type | Wi-Fi 5 Di-Pole antennas (and high powered amplifiers) for expanded coverage |
| Antenna Gain WiFi |
2412–2472 MHz: 3.1 dBi 5180–5240 MHz: 4.8 dBi 5260–5730 MHz: 5.1 dBi 5500–5700 MHz: 5 dBi |
| Output Power (EIRP) WiFi |
2412–2472 MHz: 19.77 dBm Beamforming: 19.73 dBm 5180–5240 MHz: 22.80 dBm Beamforming: 22.76 dBm 5260–5320 MHz: 22.49 dBm Beamforming: 22.45 dBm 5500–5700 MHz: 29.99 dBm Beamforming: 29.87 dBm |
| Antenna Gain Bluetooth | 2 dBi |
| Power Adapter |
Input: 100–240 V, 50–60 Hz, 0.9 A Output: 12 V, 3 A |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | –20°C to 70°C |
| Humidity Range | 10% to 80% RH (non-condensing) |
| Dimensions (individual node) |
Weight: 0.95 kg Depth: 11 cm Width: 11 cm Height: 25.9 cm |
MX4200
